SPEC

SPECS
- neck type
- Wizard III Maple neck
- top/back/body
- Meranti body
- fretboard
- Jatoba fretboard Sharktooth inlay
- fret
- Jumbo frets
- number of frets
- 24
- bridge
- Edge-Zero II bridge
- string space
- 10.8mm
- neck pickup
- Quantum (H) neck pickup Passive/Ceramic
- middle pickup
- Quantum (S) middle pickup Passive/Alnico
- bridge pickup
- Quantum (H) bridge pickup Passive/Ceramic
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D'Addario® EXL120
- string gauge
- .009/.011/.016/.024/.032/.042
- nut
- Locking nut
- hardware color
- Black
NECK DIMENSIONS
- - Scale :
  - 648mm/25.5"
  - a : Width
  - 43mm at NUT
  - b : Width
  - 58mm at 24F
  - c : Thickness
  - 19mm at 1F
  - d : Thickness
  - 21mm at 12F
  - Radius :
  - 400mmR
- DESCRIPTION
SWITCHING SYSTEM

DESCRIPTION
CONTROLS

DESCRIPTION
OTHER FEATURES
- Recommended Case
- M300C
- Recommended Bag
- IGB540-BK

Features

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.

Mono-unit output jack

The mono-unit output jack is made of solid, durable material and is a single piece to avoid unwanted movement and loosening of the jack, which leads to contact failure or disconnection. This innovation allows for long term playing enjoyment and minimal maintenance.

Edge-Zero II tremolo bridge

The Edge Zero II bridge design features a lower profile tremolo for playing comfort and stud lock function for stable tuning.

Quantum pickups

The Quantum pickups provide accelerated bass response for exceptionally fast tracking of high-speed staccato riffing with crushing mid range and precise high-end articulation.

Wizard III Maple neck

Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability and features a two-octave 24-fret fretboard for a wide tonal range.
